Machine width

mm

1270

Machine height

mm

1135

Table height

mm

850

Table of planning machine

mm

1085X256

Table of thicknessing machine

mm

600X248

Sliding table

mm

400X250

Machine weight

kg

280

Rated voltage

V

230(±10%)

Rated frequency

Hz

50(±1)

Circular saw

max. saw disc Ø

mm

200

Saw disc spindle Ø

mm

30

Saw disc rotation speed at 50Hz

min^-1

4750

Saw disc tilting

0⁰-45⁰

Max. cut height at 0⁰

mm

50

Motor power output

kW

1.1

Moulding machine

spindle Ø

mm

30

Spindle rotation speed

min^-1

6500

Clamping length of spindle

mm

80

Max. lift of the spindle

mm

80

Max. hole in the table

mm

144

Motor power output

kW

1.1

Planer and thicknessing machine

Cutter block Ø

mm

75

Cutter block knives number

pcs.

3

Cutter block rotation speed

min^-1

4000

Feeding rollers Ø

mm

32

Max. planing width

mm

250

Max. depth of planning

mm

5

Angle of workpiece fence

⁰

Max. thicknessing width

mm

248

Max. depth of thicknessing

mm

2.5

Max. workpiece height of thicknessing

mm

190

Feeding speed

m/min

8

Motor power output

kW

1.5

Load

LpAeq =89.5 dB(A)

Level of acoustic power A (LWA)

No-load

LWA = 94.5 dB(A)

Load

LWA = 103 dB(A)
