Motors

2x1500W+1x1100W 230V/50Hz or 400V

Bench Saw

Planer & Thicknesser

Table size

940x410mm

Planer table size

1085x253mm

Sliding table size

400x250mm

Thicknesser table size

248x600mm

Blade diameter

Φ200mm

Blade speed

4000rpm

Blade speed

4750rpm

Blade size

250x30x3mm

Cutting capacity

60mm/90°;38mm/45°

Max cut depth of planer

5mm

Max cut depth of thicknesser

2.5mm

Spindle Moulder

Thicknesser capacity

195mm

Table size

940x410mm

Thicknesser feed speed

8m/min

Spindle size

Φ30mm

Spindle travel

80mm

Sliding carriage

Max tooling diameter

140mm

Sliding table size

400x250mm

Spindle speed

4000/6000/8000rpm

Traveling distance

750mm

Package

Mortiser(optional)

Packing size

113x50x74cm

Chuck

16mm

113x69x57cm

Table size

370x150mm

NW/GW

112/148kgs

Vertical stroke

0-80mm

169/200kgs

Lateral stroke

0-140mm

Qty/20' ctnr

32pcs

Net weight

25kg
